From Acronyms to Action
In structured cabling, electrical, and limited energy systems, precision starts with language. Whether you're reviewing submittals, coordinating trades, or troubleshooting in the field, abbreviations and acronyms are everywhere—and misreading one can derail the job. This guide consolidates the most relevant terms across cabling, electrical, security, access control, and A/V disciplines, ensuring clarity from spec to site.
To streamline your documentation and sharpen field communication, here’s a categorized glossary of abbreviations and acronyms—organized by domain for rapid reference and cross-disciplinary alignment.
Structured Cabling & Network Infrastructure
AP: Access Point
AWG: American Wire Gauge
BMS: Building Management System
BNC: Bayonet‑Neill‑Concelman
BOM: Bill of Materials
CDDI: Copper Distributed Data Interface
CL2 / CL3: Class 2 / Class 3 Power‑Limited Circuits
CL2P / CL3P: Plenum‑Rated Class 2 / Class 3 Cable
CL2R / CL3R: Riser‑Rated Class 2 / Class 3 Cable
CM / CMR / CMP: Communications Cable / Riser / Plenum
CP: Consolidation Point
CRAC / CRAH: Computer Room Air Conditioner / Air Handler
DCIM: Data Center Infrastructure Management
dB / dBm: Decibel / Decibel‑milliwatt
DWDM: Dense Wavelength Division Multiplexing
ELFEXT: Equal Level Far End Crosstalk
EMI: Electromagnetic Interference
ENT: Electrical Nonmetallic Tubing
ER: Equipment Room
FEXT: Far‑End Crosstalk
FOTP: Fiber Optic Test Procedure
FTP: Foil Twisted Pair
HC: Horizontal Cross‑Connect
Horiz.: Horizontal
IC: Intermediate Cross‑Connect
IDC: Insulation Displacement Connection
IDF / MDF: Intermediate Distribution Frame / Main Distribution Frame
ISP / OSP: Inside Plant / Outside Plant
LAN: Local Area Network
LC / SC / ST: Common Fiber Connector Types
LP: Limited Power (Cable Marking per NEC)
MAC (Moves, Adds, Changes): Cabling Changes in Existing Infrastructure
MC: Main Cross‑Connect
MHz: Megahertz
MM / SM: Multimode / Singlemode
MPO: Multi‑Fiber Push‑On Connector
MTP: Branded MPO Variant
MUTOA: Multi‑User Telecommunications Outlet Assembly
N+1 / 2N: Redundancy Models
NEXT / PSNEXT: Near‑End Crosstalk / Power Sum NEXT
OLTS: Optical Loss Test Set
OM1–OM5: Optical Multimode Fiber Classes
OS1 / OS2: Optical Singlemode Fiber Types
OTDR: Optical Time Domain Reflectometer
PoE / PoE+ / PoE++ / UPoE: Power over Ethernet Variants
QoS: Quality of Service
RMS: Rack Mount Space
RNC: Rigid Nonmetallic Conduit
RTRC: Reinforced Thermosetting Resin Conduit
ScTP / STP / UTP: Screened / Shielded / Unshielded Twisted Pair
SFP / SFP+ / QSFP: Small Form‑Factor Pluggable Transceivers
SN: Small‑Form Next‑Gen Fiber Connector
SNMP: Simple Network Management Protocol
TC: Telecommunications Closet
TIA: Telecommunications Industry Association
TP / TP‑PMD: Transition Point / Twisted Pair – Physical Medium Dependent
TSB: Telecommunications System Bulletin
UPC / APC: Ultra Physical Contact / Angled Physical Contact
Vert.: Vertical
VLAN: Virtual Local Area Network
WDM / CWDM: Wavelength Division Multiplexing / Coarse WDM
Electrical Systems & Power Distribution
AC / DC: Alternating Current / Direct Current
AFCI: Arc‑Fault Circuit Interrupter
AIC: Ampere Interrupting Capacity
AMP: Ampere
ATS: Automatic Transfer Switch
CB: Circuit Breaker
CI / CII / CIII: Circuit Integrity Cable Ratings
CRAC / CRAH: Computer Room Air Conditioner / Air Handler
CU / AL: Copper / Aluminum
DER: Distributed Energy Resource
EGC: Equipment Grounding Conductor
EMT / IMC / GRS: Electrical Metallic Tubing / Intermediate Metal Conduit / Galvanized Rigid Steel
ESS: Energy Storage System
FPL / FPLR / FPLP: Fire Alarm Cable (General / Riser / Plenum)
GEC: Grounding Electrode Conductor
GE: Grounding Electrode
GFCI: Ground‑Fault Circuit Interrupter
GND / EG / IG: Ground / Equipment Ground / Isolated Ground
HV / LV: High Voltage / Low Voltage
HVAC: Heating, Ventilation, and Air Conditioning
KV / KVA / KW / KWH: Kilovolt / Kilovolt‑Ampere / Kilowatt / Kilowatt‑Hour
MCA / MCB / MCC / MDP: Minimum Circuit Ampacity / Breaker / Control Center / Distribution Panel
MI Cable: Mineral‑Insulated Cable
OCPD: Overcurrent Protective Device
PDU: Power Distribution Unit
PF: Power Factor
PLTC: Power‑Limited Tray Cable
RPP: Remote Power Panel
SDT: Screw Down Termination
SPD: Surge Protective Device
THHN / THWN: Common Building Wire Insulation Types
UPS: Uninterruptible Power Supply
VFD: Variable Frequency Drive
Security, Access Control & Authentication
ACU: Access Control Unit
AES: Advanced Encryption Standard
AES‑256: 256‑bit Encryption Standard
CCTV: Closed‑Circuit Television
FIPS: Federal Information Processing Standards
FOV: Field of View
H.264 / H.265: Video Compression Standards
HID: Human Interface Device
LPR: License Plate Recognition
MAC: Media Access Control
MFA: Multi‑Factor Authentication
NDAA: National Defense Authorization Act (Camera Compliance)
ONVIF: Open Network Video Interface Forum
OTP: One‑Time Password
PACS: Physical Access Control System
PIN: Personal Identification Number
RFID: Radio Frequency Identification
SDK: Software Development Kit
SSL / TLS: Secure Sockets Layer / Transport Layer Security
Wiegand: Wiegand Interface Protocol
Audio/Visual & Surveillance
AV: Audio/Visual
CCTV: Closed‑Circuit Television
CEC: Consumer Electronics Control (HDMI)
DVR / NVR: Digital Video Recorder / Network Video Recorder
EDID: Extended Display Identification Data
HDR: High Dynamic Range
HDBaseT: AV Transport Standard
HDMI: High‑Definition Multimedia Interface
IPCAM: Internet Protocol Camera
IR / INFRA: Infrared
LFE: Low‑Frequency Effects (Audio)
PTZ: Pan‑Tilt‑Zoom Camera
RTMP: Real‑Time Messaging Protocol
RTSP: Real‑Time Streaming Protocol
SDI / HD‑SDI: Serial Digital Interface / High‑Definition SDI
SIP: Session Initiation Protocol
SPL: Sound Pressure Level
VMS: Video Management System
WDR: Wide Dynamic Range
Trade Associations & Standards Bodies
ANSI: American National Standards Institute
AVIXA: Audiovisual and Integrated Experience Association
BICSI: Building Industry Consulting Service International
cULus: Canadian and U.S. Listing by Underwriters Laboratories
EIA / TIA: Electronic Industries Alliance / Telecommunications Industry Association
ETL: Electrical Testing Laboratories (Intertek)
FCC: Federal Communications Commission
IEEE: Institute of Electrical and Electronics Engineers
ISO: International Organization for Standardization
ISO/IEC JTC 1/SC 25: Interconnection of Information Technology Equipment
NEIS: National Electrical Installation Standards
NEMA: National Electrical Manufacturers Association
UL: Underwriters Laboratories
Industry Abbreviations
AEC: Architecture, Engineering, and Construction
AHJ: Authority Having Jurisdiction
AIA: American Institute of Architects
ASTM: American Society for Testing and Materials
BIM: Building Information Modeling
BOMA: Building Owners and Managers Association
CO: Change Order
CSI: Construction Specifications Institute
CSA: Canadian Standards Association
DD / CD: Design Development / Construction Documents
FM: Factory Mutual (FM Approvals)
GC / EC / LV: General Contractor / Electrical Contractor / Low‑Voltage Contractor
IBC: International Building Code
ICC: International Code Council
LEED: Leadership in Energy and Environmental Design
MEP: Mechanical, Electrical, Plumbing
NEC: National Electrical Code
NFPA: National Fire Protection Association
NRTL: Nationally Recognized Testing Laboratory
OSHA: Occupational Safety and Health Administration
PE: Professional Engineer
PM: Project Manager
QA / QC: Quality Assurance / Quality Control
RFI: Request for Information
RFP / RFQ: Request for Proposal / Request for Quote
SOW: Scope of Work
T&M: Time and Materials
Whether you're drafting specs, reviewing submittals, or troubleshooting in the field, this glossary keeps your language sharp, your documentation clean, and your installs built to last.
